Product Description
1.1 Scintillator: CsI ;
1.2 Image size:14×17 inch;
1.3 Pixels:22304 x 2800
1.4 Dimensions:460*460*16mm
1.5 Pixel Pitch:150µm;
Product Parameters
| Model NO. | Specification | Brand | Feature |
| MSLFP01 | 17*17 COS Mobile Flat Panel Detector | MSL | DICOM DR workstaton |
| MSLFP02 | 17*17 CIS Mobile Flat Panel Detector | MSL | DICOM DR workstaton |
| MSLFP07 | 10*12 CSI Mammography Detector | MSL | DICOM DR workstaton |
Product Technical Parameters:
| Detector Technology | Amorphous Silicon |
| Scintillator | CsI |
| Active Area | 345.6mm x 420mm |
| Number of Pixels | 2304 x 2800 |
| Pixel Pitch | 150 um |
| AD Conversion | 16 bit |
| Trigger Mode | AED/Software |
| Data Interface | Ethernet/WiFi(802.11ac) |
| Dimension | 384mm x 460mm x 15mm |
| Weight | 3.6 kg |
| Drop Height | 120cm |
| Static Loading | 150kg Uniformly |
| Battery Capacity | 5 h |
| Sensitivity(LSB/uGy) | Typ. 750 |
| MTF@ 0 LP/mm (@RQA5, Typ.) | 1 |
| MTF @ 1.0 LP/mm (@RQA5, Typ.) | 67% |
| MTF @ 2.0 LP/mm (@RQA5, Typ.) | 46% |
| MTF @ 3.0 LP/mm (@RQA5, Typ.) | 28% |
| DQE @ 0 LP/mm (@RQA5, Typ.) | 59% |
| DQE @ 1.0 LP/mm (@RQA5, Typ.) | 40% |
| DQE @ 2.0 LP/mm (@RQA5, Typ.) | 27% |
| DQE @ 3.0 LP/mm (@RQA5, Typ.) | 14% |
| Limiting Resolution (without phantom or grid) | 3.3 lp/mm |
| Trigger Mode | AED/Software |
| Preview Image | Typ. 3s |
| Full Image Time | Typ. 5s |
| Cycle Time | Typ. 8s |
| Operating Temperature | 5ºC~35ºC |
| Storage & Transport Temperature with Package | -20ºC~55ºC |
| Operating Humidity | 10%~90% |
| Storage & Transport Humidity with Package | 5%~95% |
| Operating Atmospheric Pressure | 700mbar~1060mbar |
| Storage & Transport Atmospheric Pressure | 700mbar~1060mbar |
Packing & Delivery
Carton box package
1pcs will be packaed in one carton
Carton size: 70*10*28cm
Gross weight: 7kgs
Shipping methods: by DHL/FEDEX,UPS/TNT/ARAMEX and so on
BY sea or by air
Goods ready time: 3-7 working days after payment
Delivery: 4-5days by DHL
30days by Sea
